252
NAME VALUE SECURITY
(get/set)
DESCRIPTION
stopbit 1,2 4/4 "1" :Onestopbitistransmittedto
indicatetheendofabyte.
"2":Twostopbitsaretransmittedto
indicatetheendofabyte.
Ifyouwanttotransferthe stopbitfo r
150%ofthenormaltimeusedto
transferonebit,the
uart_i<0~(n‐1)>_stopbitshouldbeset
as2andtheuart_i<0~(n‐1)>_databit
setas5aswell.
uartmode rs485 4/7 RS485mode.

7.44 UARTControl(SCSeries)
Group:uart_i<0~(n‐1)>nisuartportcount(capability_nuart>0andcapability_ibis=1)
NAME VALUE S ECURITY
(get/set)
DESCRIPTION
baudrate 1200,2400,4800,960
0,19200,38400
4/4 Setbaudra teofCOMport.

databit 5,6,7,8 4/4 Databitsinacharacterframe.
paritybit none,
odd,
even
4/4 Forerrorchecking.
stopbit 1,2 4/4 "1":Onestopbitistransmittedto
indicatetheendofabyte.
"2":Twostopbitsaretransmittedto
indicatetheendofabyte.
Ifyouwanttotransferthe stopbitfo r
150%ofthenormaltimeusedto
transferonebit,the
uart_i<0~(n‐1)>_stopbitshouldbeset
as2andtheuart_i<0~(n‐1)>_databit
setas5aswell.

7.45 LensConfiguration
