3 Technical data
Function conditions for standard design
Conditions ZB range
Transport temperature -20 ... +40 °C
Storage temperature 0 ... +40 °C
Storage conditions Dry, indoors
Ambient operating temperature -20 ... +40 °C
Environment Acid-free
Coolant Air
Coolant temperature Max. +40 °C
Temperature rise limit of winding 105 K
Site altitude Max. 1000 m above sea level
Air circuit Ensure by working clearance, unrestricted air intake
Type of enclosure IP54
Mounting arrangement Low vibration
Working clearance at fan end 150 mm at rear
Line voltage 400V/50 Hz 480V/60 Hz 500V/50 Hz
Voltage tolerance ±10% of the line voltage for short periods according to IEC 38
Maximum speeds in rpm
Motor frame size with operational braking
(line operation)
Motor frame size with occasional emergen-
cy stop
(inverter operation)
ZBF 63 – 132 3600 – –
ZBA 63 – 132
ZBE 63 – 80A
ZBP 80B – 132
3600
ZBA/ZBE 63 – 100
ZBP 80B – 100
5000
ZBA/ZBE/ZBP 112 – 132 4000
ZBA/ZBE/ZBP 160 – 180A, with B140 brake
ZBA/ZBE/ZBP 160 – 180A 3600
ZBA/ZBE/ZBP 160 – 180A, with B280 brake
2000
ZBA 180B – 225 ZBA/ZBE 180B – 225 3000
