4. SPECIFICATIONS
Description Parameters
CD Transport Proprietary FPGA DSP Processing Architecture
FIFO Buffer and Reclock with Internal Crystal / External Clock
FEMTO CLOCK
Optical Isolated All Digital Input Interfaces
External Master Clock Input Supported
Upsampling Frequency 44.1, 88.2, 176.4, 352.8 KHz
Digital Output
PCM
16bits / 44.1, 88.2, 176.4, 352.8KHz
External Clock Input Master Clock (22.5792Mhz / 45.1584Mhz) via 75ohms BNC
Digital Output Coax SPDIF via RCA
TOSLink
AES/EBU
I²S HDMI LVDS Standard
I²S RJ45 LVDS Standard
I²S RJ45 LVCMOS Standard
AC Power Requirement 110-240VAC, 50/60Hz
Power Consumption
≤20W
Dimension
436W x 368D x 93H mm (Feet +18mm)
Weight
12 Kg
Colour Silver / Black
Warranty 12 Months
