7
. Remote control receiving window
The remote control receiving signal window , cannot be blocked, otherwise it will affect the remote control
receiving signal.
Kind Reminder: The DAC device does not come with a remote control, which needs to be purchased
separately.
3
Schematic diagram of the effective working angle and distance range of the remote control.
ON
ANALOG
DIGITAL
OPEN TIME0
SOURCE
- +
2 31
5 64
8 97
REPEAT
SCAN REV
PREV
PLAYSTOP PAUSE
PROGRAM NEXT
FWD
A-B RANDOM
- +
SOURCE
OFF
MUTE
VOL +
VOL -
POWER
Receiving end: with the infrared receiving window
as the axis of the Plus or minus 30 degrees cone
range;
Effective remote control
Distance: ≤8m
Transmitter: A conical range of ±10 degrees
centered on the infrared emitter.
