DiaDENS PCM 6 2017 – Operating Manual
6
Shop at -
www.coachjimmyk.com
MUSCLES
Zone 1 : Impuls packets with duration of 380±38 msec, repetition frequency
of 1 Hz, and carrier frequency of 125 Hz. The duration of the first phase of
the impulse is variable (15 min)
over 1 year
MUSCLES
Zone 1 : 10 Hz (10 min)
Zone 2 : «7720» (10 min)
any age
POTENCY
Zone 1 : 2,6 Hz (5 min) + 4,0 Hz (5 min) + 9,4 Hz (5 min)
Zone 2 : «7710» (15 min)
Zone 3 : 10 Hz (5 min) + 20 Hz (5 min)
over 13 years
KIDNEYS
Zone 1 : 77 Hz (10 min) + 20 Hz (10 min)
Zone 2 : 2,8 Hz (5 min) + 8,1 Hz (5 min) + «7710» (5 min)
over 7 years
BACK
Zone 1 : 140 Hz (5 min) + 77 Hz (5 min) + 20 Hz (5 min)
over 4 years
JOINTS
Zone 1 : 140 Hz (5 min) + 77 Hz (5 min) + 20 Hz (5 min) + 1,6 Hz (5 min)
Zone 2 : «7710» (10 min)
over 7 years
NAUSEA
Zone 1 : «7710» (10 min)
over 4 years
TRAUMA
Zone 1 : 200 Hz (5 min) + 140 Hz (5 min) + 77 Hz (5 min)
over 1 year
ASPHYXIA
Zone 1 : «7710» (10 min)
Zone 2 : 1,0 Hz (3 min) + 8,0 Hz (3 min) + 3,6 Hz (3 min)
any age
3.4 Maximum consumption current (with supply voltage of 3 V) is not more than 300 mA.
3.5 Power supply source: batteries of LR6/ type, 2 pieces with voltage of 1.5 V. It is allowed to use the relevant storage
batteries with voltage of 1.2 V*.
3.6 The device weighs not more than 0.35 kg.
3.7 The overall dimensions of the device are not more than 165x65x65 mm.
3.8 The device automatically switches off not later than 5 minutes after one of its keys (except for key) has last been
pressed, after the electrodes have been released from skin, or after the stimulation period has finished.
*Operation procedure (recharger types, recharge methods) is described in the storage battery instruction manual. Duration of the device service when
used with storage batteries depends on characteristics of the batteries.
3.9 Electromagnetic Radiation
Test
Conformity to IEC 60601-1-2
Conditions of Use
Radiofrequency
radiation
CISPR 11
Class B
DENAS-PCM Electrical Stimulator can be used in all types of
institutions and at home as well
Group 1
DENAS-PCM emits very little radio-frequency radiation that
cannot lead to failure of electronic equipment located nearby
3.10 Resistance to radio-frequency radiation
Test
IEC 60601-1-2 test conditions
Acceptable level
IEC 61000-4-6
3 Vrms oТ 150 kHz Дo 80 MHz
3 Vrms
IEC 61000-4-3
3 V/m oТ 80 MHz Дo 2,5 GHz
3 V/m
3.11 Resistance to electromagnetic fields.
Magnetic fields
Test level
Conformity level
Conditions of Use
Electrostatic discharge
(ESD) IEC
61000-4-2
±6 kV contact;
±8 kV air
±4 kV contact;
±8 kV air
The floor should be made of wood, concrete or
ceramic tiles. If the floor is covered with synthetic
material, the relative air humidity should be not less
than 40%.
Magnetic fields IEC
61000-4-8
3 A/m
3 A/m
Magnetic field parameters should be within the
normal values for commercial buildings and
healthcare facilities.
