8.03 Rear Roller - Outer Roller Assembly
Item No. Part Number Description Quantity
1 J179540 17” LH Outer Roller c/w Bush 1
1 J179541 17” RH Outer Roller c/w Bush 1
1 800019L 20” LH Outer Roller c/w Bush 1
1 800019R 20” RH Outer Roller c/w Bush 1
1 800044L 24” LH Outer Roller c/w Bush 1
1 800044R 24” RH Outer Roller c/w Bush 1
2 J20476 Plunger Bush 1
3 J20435 Spring Plunger 1
4 J20437 Plunger Pawl 1
6 J20480 Grease Nipple 67 Deg 1/8” Bsp T 1
7 J20481 Grease Nipple Extension 1/8” Bsp T 1
8 J20473 Roller Bush 2
Not Shown
- J20404 Pin Spirol M5 x 24 1
3
1
2
4
6
7
8
