Denon AVR-S540BT User Manual

o
Sound is interrupted or noise occurs
Symptom Cause / Solution Page
During playback from the
USB memory device,
sound is occasionally
interrupted.
0
When the transfer speed of the USB memory device is slow, sound may occasionally be interrupted. －
Noise often occurs in
FM/AM broadcasting.
0
Change the antenna orientation or position. 34
0
Separate the AM loop antenna from the unit. －
0
Use an outdoor antenna. 34
0
Separate the antenna from other connection cables. 34
The sounds appear to be
distorted.
0
Lower the volume. 39
0
Set “Off” to the ECO Mode. When “On” or “Auto” is in the ECO Mode, the audio may by distorted when
the playback volume is high.
92
Contents Connections Playback Settings Tips Appendix
106
Front panel Display Rear panel Remote Index

Denon AVR-S540BT Specifications

General

Channels	5.2
Power Output per Channel	70 W (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive)
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
HDMI Inputs	5
HDMI Outputs	1
HDMI Version	2.0a
HDCP Support	2.2
4K/60 Hz Pass-through	Yes
Dolby Format	Dolby TrueHD, Dolby Digital Plus
DTS Format	DTS-HD Master Audio
Auto Speaker Setup	Yes (Audyssey MultEQ)
Bluetooth	Yes
FM Tuner	Yes
AM Tuner	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
Dimensions (W x H x D)	434 x 151 x 319 mm
Ethernet Port	No
Wi-Fi	No
HDR Support	HDR10, HLG
Frequency Response	10 Hz - 100 kHz - +1/-3 dB
Total Harmonic Distortion	0.08% (20 Hz - 20 kHz)
Signal-to-Noise Ratio	98 dB (IHF-A weighted)
USB Port	Yes (Front)
