Denon AVR-S540BT User Manual

Adjusting the tone (Tone)
Adjusts the tonal quality of the sound.
1
Press OPTION.
The option menu screen is displayed.
2
Use ui to select “Tone”, then press ENTER.
The “Tone” screen is displayed.
3
Use o p to set the tone control function to on/off.
On: Allow tone adjustment (bass, treble).
Off
(Default):
Playback without tone adjustment.
4
Select “On” in step 3 and press i to select the sound
range to be adjusted.
Bass: Adjust bass.
Treble: Adjust treble.
5
Use o p to adjust the tone, then press ENTER.
-6 dB – +6 dB (Default : 0 dB)
o
Operating the unit
n
Setting the tone control function
Press TONE CONTROL ON/OFF.
n
Select the range for which to adjust the tone.
Press BASS/TREBLE.
n
Adjusting the tone
Press ADJUST 0 or ADJUST 1.
0
“Tone” settings are stored for each input source.
0
This cannot be set when the sound mode is set to “Direct”.
0
You cannot set this when no audio signal is input or in the menu “HDMI Audio Out”
is set to “TV”. (v p. 77)
Contents
Connections Playback Settings Tips Appendix
54
Front panel Display Rear panel Remote Index

Denon AVR-S540BT Specifications

General

Channels	5.2
Power Output per Channel	70 W (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive)
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
HDMI Inputs	5
HDMI Outputs	1
HDMI Version	2.0a
HDCP Support	2.2
4K/60 Hz Pass-through	Yes
Dolby Format	Dolby TrueHD, Dolby Digital Plus
DTS Format	DTS-HD Master Audio
Auto Speaker Setup	Yes (Audyssey MultEQ)
Bluetooth	Yes
FM Tuner	Yes
AM Tuner	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
Dimensions (W x H x D)	434 x 151 x 319 mm
Ethernet Port	No
Wi-Fi	No
HDR Support	HDR10, HLG
Frequency Response	10 Hz - 100 kHz - +1/-3 dB
Total Harmonic Distortion	0.08% (20 Hz - 20 kHz)
Signal-to-Noise Ratio	98 dB (IHF-A weighted)
USB Port	Yes (Front)
