5
2) Connect the receiver to your home network
Wired LAN
Connect an Ethernet cable (not included) between your
receiver and your network router.
Router
To LAN port
Wireless LAN
Rotate the two antennas located on the back of the receiver
upwards for maximum performance.
1. AVR-S740HE3_QSG_ENG_00A_180124.indd 5 2018/02/02 13:11:45
PrintingColor:Black

Table of Contents

Other manuals for Denon AVR-S740H

Preview: Owner's Manual
Owner's Manual272 pages
Preview: Service Manual
Service Manual155 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-S740H and is the answer not in the manual?

Denon AVR-S740H Specifications

General IconGeneral
Channels7.2
Power Output per Channel75 W (8 Ohms, 20 Hz - 20 kHz, 0.08% THD)
HDMI Inputs6
HDMI Outputs1
Dolby AtmosYes
DTS:XYes
BluetoothYes
Wi-FiYes
HEOS Multi-roomYes
4K Ultra HD Pass-throughYes
Power Output per Channel (6 Ohms)110 W (6 Ohms, 1 kHz, 0.7% THD)
4K/Ultra HD UpscalingYes
Phono InputYes
Dolby SupportDolby Atmos, Dolby TrueHD, Dolby Surround
Auto CalibrationAudyssey MultEQ
Input Sensitivity/Impedance200 mV / 47 kOhms
Signal-to-Noise Ratio98 dB (IHF-A weighted, Direct mode)
EthernetYes
USB PortYes (front)
AM/FM TunerYes
Supported Audio FormatsMP3, WMA, AAC, FLAC, ALAC, WAV, DSD
HDR SupportHDR10, HLG, Dolby Vision
Wireless AudioAirPlay 2
DTS SupportDTS:X, DTS-HD Master Audio
Zone AudioZone 2
Frequency Response10 Hz - 100 kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion0.08% (20 Hz - 20 kHz)
Built-in DAC192 kHz / 24-bit
