Connecting a set-top box (Satellite tuner/cable TV)
This explanation uses the connection with a satellite tuner/cable TV STB as an example.
Select the input connectors on this unit to match the connectors on the device that you want to connect to.
.
R
L
R
L
OUT
HDMI
OUT
COAXIAL
AUDIO
AUDIO
RL
OUT
OUT
VIDEO
VIDEO
(HDMI incompatible device)
or
Satellite tuner /
Cable TV
Satellite tuner /
Cable TV
Contents
Connections Playback Settings Tips Appendix
52
Front panel Display Rear panel Remote Index

Other manuals for Denon AVR-S740H

Preview: Service Manual
Service Manual155 pages
Preview: Quick Start Guide
Quick Start Guide12 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-S740H and is the answer not in the manual?

Denon AVR-S740H Specifications

General IconGeneral
Channels7.2
Power Output per Channel75 W (8 Ohms, 20 Hz - 20 kHz, 0.08% THD)
HDMI Inputs6
HDMI Outputs1
Dolby AtmosYes
DTS:XYes
BluetoothYes
Wi-FiYes
HEOS Multi-roomYes
4K Ultra HD Pass-throughYes
Power Output per Channel (6 Ohms)110 W (6 Ohms, 1 kHz, 0.7% THD)
4K/Ultra HD UpscalingYes
Phono InputYes
Dolby SupportDolby Atmos, Dolby TrueHD, Dolby Surround
Auto CalibrationAudyssey MultEQ
Input Sensitivity/Impedance200 mV / 47 kOhms
Signal-to-Noise Ratio98 dB (IHF-A weighted, Direct mode)
EthernetYes
USB PortYes (front)
AM/FM TunerYes
Supported Audio FormatsMP3, WMA, AAC, FLAC, ALAC, WAV, DSD
HDR SupportHDR10, HLG, Dolby Vision
Wireless AudioAirPlay 2
DTS SupportDTS:X, DTS-HD Master Audio
Zone AudioZone 2
Frequency Response10 Hz - 100 kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion0.08% (20 Hz - 20 kHz)
Built-in DAC192 kHz / 24-bit
