Explanation of terms
o
Audyssey
Audyssey Dynamic EQ
®
Audyssey Dynamic EQ
®
solves the problem of deteriorating sound quality
as volume is decreased by taking into account human perception and
room acoustics.
Audyssey Dynamic EQ
®
works in tandem with Audyssey MultEQ
®
to
provide well-balanced sound for every listener at any volume level.
Audyssey Dynamic Volume
®
Dynamic Volume solves the problem of large variations in volume level
between television programs, commercials, and between the soft and loud
passages of movies. Audyssey Dynamic EQ
®
is integrated into Dynamic
Volume so that as the playback volume is adjusted automatically, the
perceived bass response, tonal balance, surround impression, and dialog
clarity remain the same.
Audyssey MultEQ
®
Audyssey MultEQ
®
is a room equalization solution that calibrates any
audio system so that it can achieve optimum performance for every
listener in a large listening area. Based on several room measurements,
MultEQ
®
calculates an equalization solution that corrects for both time and
frequency response problems in the listening area and also performs a
fully automated surround system setup.
o
Dolby
Dolby Atmos
Introduced first in the cinema, Dolby Atmos brings a revolutionary sense of
dimension and immersion to the Home Theater experience. Dolby Atmos
is an adaptable and scalable object based format that reproduces audio
as independent sounds (or objects) that can be accurately positioned and
move dynamically throughout the 3 dimensional listening space during
playback. A key ingredient of Dolby Atmos is the introduction of a height
plane of sound above the listener.
Contents
Connections Playback Settings Tips Appendix
244
Front panel Display Rear panel Remote Index

Other manuals for Denon AVR-S750H

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-S750H and is the answer not in the manual?

Denon AVR-S750H Specifications

General IconGeneral
Receiver typestereo
Frequency range10 - 100000 Hz
Input sensitivity200 mV
Audio output channels7.2 channels
Signal-to-Noise Ratio (SNR)98 dB
Total Harmonic Distortion (THD)10 %
Power output per channel (1KHz@6 Ohm)165 W
Power output per channel (20-20KHz@8 Ohm)75 W
AirPlayYes
DisplayVFL
HDCP version2.3
Apple dockingNo
Product colorBlack
Audio decodersDTS-HD Master Audio, Dolby TrueHD
Volume controlRotary
HDMI in6
Composite video in2
Digital audio optical in1
Package depth432 mm
Package width523 mm
Package height229 mm
Package weight10614 g
AC input voltage120 V
AC input frequency60 Hz
Power consumption (standby)0.5 W
Power consumption (typical)400 W
AM band range520 - 1710 kHz
FM band range87.5 - 107.9 MHz
Supported radio bandsAM, FM
Audio formats supportedAAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Image formats supportedJPEG
Speakers connectivity typeRCA
Weight and Dimensions IconWeight and Dimensions
Depth330 mm
Height152 mm
Weight8618 g
