5
2) Connect the receiver to your home network
Wired LAN
Connect an Ethernet cable (not included) between your
receiver and your network router.
Router
To LAN port
Wireless LAN
Rotate the two antennas located on the back of the receiver
upwards for maximum performance.
1. AVR-X1600HE2_QSG_ENG_00A_190315.indd 5 2019/03/22 9:26:49
PrintingColor:Black

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X1600 DAB and is the answer not in the manual?

Denon AVR-X1600 DAB Specifications

General IconGeneral
Channels7.2
HDMI Inputs6
HDMI Outputs1
Dolby AtmosYes
DTS:XYes
BluetoothYes
Wi-FiYes
HEOS Multi-roomYes
Voice ControlAmazon Alexa, Google Assistant, Apple Siri
HDMI 2.1 SupportNo
4K/60Hz Pass-throughYes
eARCYes
Auto CalibrationAudyssey MultEQ XT
Frequency Response10Hz - 100kHz
Total Harmonic Distortion0.08%
Input Sensitivity200mV
Signal-to-Noise Ratio98dB
Ethernet PortYes
Dimensions434 x 151 x 339 mm
Weight8.6 kg
Power Output80W per channel (8 ohms, 20Hz - 20kHz, 0.08% THD)
TunerDAB/DAB+/FM
HDR SupportHDR10, HLG, Dolby Vision
Streaming ServicesSpotify, Tidal, Deezer
USB Port1 front
