Speaker configuration and “Amp Assign” settings
This unit has a built-in 7-channel power amplifier. In addition to the basic 5.1-channel system, a variety of speaker systems can be configured by changing
the “Amp Assign” settings to suit the application, such as 7.1-channel systems, bi-amp connections and 2-channel systems for multi-zone playback.
(v p. 198)
Perform “Amp Assign” settings to suit the number of rooms and speaker configuration to be installed. (v p. 198)
Playback speaker and zone
“Amp Assign” settings
Connection
page
MAIN ZONE ZONE2
5.1-channel Not used Can be set in all “Amp Assign” modes. 39
7.1-channel (surround back) Not used Surround Back (Default) 40
7.1-channel (front height) Not used Front Height 41
7.1-channel (top front) Not used Top Front 42
7.1-channel (top middle) Not used Top Middle 43
7.1-channel (front Dolby Atmos Enabled speaker) Not used Front Dolby 44
7.1-channel (surround Dolby Atmos Enabled speaker) Not used Surround Dolby 45
5.1-channel (bi-amp connection for front speaker) Not used Bi-Amp 46
5.1-channel + second pair of front speaker Not used Front B 47
5.1-channel
2-channel
(Speaker out)
ZONE2 48
0
The sound mode that can be selected varies according to the speaker configuration. See “Sound modes and channel output” (v p. 260) for the sound modes that are
supported.
