Denon AVR-X1600H User Manual

Accessories
8
Inserting the batteries
9
Operating range of the remote control unit
9
Features
10
High quality sound
10
High performance
11
Easy operation
14
Part names and functions
15
Front panel
15
Display
18
Rear panel
20
Remote control unit
23
Connections
Speaker installation
27
Connecting speakers
34
Before connecting speakers
34
Speaker configuration and “Amp Assign” settings
38
Connecting 5.1-channel speakers
39
Connecting 7.1-channel speakers
40
Connecting 5.1-channel speakers: Bi-amp connection of front
speaker
46
Connecting 5.1-channel speakers: Second pair of front speaker
47
Connecting multi-zone speakers
48
Connecting a TV
49
Connection 1 : TV equipped with an HDMI connector and
compatible with the ARC (Audio Return Channel) / eARC
(Enhanced Audio Return Channel)
50
Connection 2 : TV equipped with an HDMI connector and
incompatible with the ARC (Audio Return Channel) / eARC
(Enhanced Audio Return Channel)
52
Connection 3 : TV equipped without an HDMI connector
53
Connecting a playback device
54
Connecting a set-top box (Satellite tuner/cable TV)
55
Connecting a DVD player or Blu-ray Disc player
56
Connecting a video camcorder or game console
57
Connecting a turntable
58
Connecting a USB memory device to the USB port
59
Connecting FM/AM antennas (for FM/AM model only)
60
Connecting a DAB/FM antenna (for FM/DAB model only)
62
Connecting to a home network (LAN)
63
Wired LAN
63
Wireless LAN
64
Connecting the power cord
65
Contents Connections Playback Settings Tips Appendix
2
Front panel Display Rear panel Remote Index

Denon AVR-X1600H Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	4 - 16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	6
AC (power) in	Yes
Composite video in	2
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Connectivity technology	Wired & Wireless
Speakers connectivity type	Clamp terminals
Display	-
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
AM band range	520 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Pandora, Spotify, Tidal, TuneIn
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	440 W
Operating temperature (T-T)	5 - 35 °C
Package weight	10600 g
Certification	CE
Package depth	435 mm
Package width	523 mm
Package height	232 mm

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	215 mm
Weight	8600 g
