Page #89 background imageLoading...
Page #89 background image
Listening to FM broadcasts
1
Connect the antenna. (“Connecting a DAB/FM antenna
(for FM/DAB model only)” (v p. 62))
2
Press TUNER to switch the input source to “Tuner”.
3
Press OPTION.
The option menu screen is displayed.
4
Use ui to select “FM/DAB”, then press ENTER.
This displays the reception band input screen.
5
Use o p to select “FM”, then press ENTER.
FM: When listening to an FM broadcast.
DAB: When listening to a DAB broadcast.
0
See “Listening to DAB broadcasts” (v p. 95) for information on
playing DAB.
G TV screen H
.
OPTION
OPTION
AUTO
AUTO
Tuner
CH 1
FM 87.50MHz
Tune Preset Option
.
01 FM 87.50MHz
GDisplay of this unitH
6
Press TUNE + or TUNE – to select the station you want
listen to.
Scanning is performed until it finds an available radio station. When
it finds a radio station, it stops the scan automatically and tunes in.
0
The modes for receiving FM broadcasts consists of “Auto” mode that automatically
searches available broadcast stations and “Manual” mode that lets you tune in
using buttons to change the frequency. The default setting is “Auto”. You can also
use “Direct Tune” to tune in by entering the frequency directly.
In “Auto” mode, you cannot tune in to radio stations if the reception is not good.
If this is the case, then use the “Manual” mode or “Direct Tune” mode to tune in.
Contents Connections Playback Settings Tips Appendix
89
Front panel Display Rear panel Remote Index
