Denon AVR-X1800H User Manual

Speakers
The acoustic characteristics of the connected speakers and listening room are measured and the optimum settings are made automatically. This is called
“Audyssey
®
Setup”.
You do not have to perform Audyssey
®
Setup when you have already performed “Speaker Calibration” in “Setup Assistant”.
To set up the speakers manually, use “Manual Setup” on the menu. (v p. 189)
Audyssey
®
Setup
To perform measurement, place the Sound calibration microphone in
multiple locations all around the listening area. For best results, we
recommend you measure in six or more positions, as shown in the
illustration (up to eight positions).
When measuring the second and subsequent positions, install the Sound
calibration microphone within 2 ft (60 cm) of the first measurement position
(main listening position).
0
If you perform Audyssey
®
Setup, Audyssey MultEQ
®
XT, Audyssey Dynamic EQ
®
and Audyssey Dynamic Volume
®
functions are enabled. (v p. 162)
FL SW C FR
SRSL
Surround speaker (R)
Surround speaker (L)
Subwoofer
Center speaker
Front speaker (R)
Front speaker (L)
( :Measuring positions)
FL
FR
C
SW
SL
SR
Listening position
Contents Connections Playback Settings Tips Appendix
179
Front panel Display Rear panel Remote Index

Denon AVR-X1800H Specifications

General

Amplifier Channels	7.2
HDMI Version	2.1
HDCP Support	2.3
eARC	Yes
Dolby Atmos	Yes
DTS:X	Yes
Dolby Surround	Yes
DTS Neural:X	Yes
Bluetooth	Yes
AirPlay 2	Yes
HEOS Multi-Room	Yes
Input Sensitivity/Impedance	200 mV / 47 kohms
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Power Output per Channel	80W (8 ohms, 20Hz - 20kHz, 0.08% THD)
HDMI Inputs	6
HDR Support	HDR10+, Dolby Vision, HLG
Wi-Fi	Yes
Phono Input	Yes
Frequency Response	10Hz - 100kHz
Total Harmonic Distortion	0.08%
Signal-to-Noise Ratio	98dB
