Explanatory Photos for DISASSEMBLY
• For the shooting direction of each photos used in this manual, see the photo below.
• A, B, C and D in the photo below indicate the shooting directions of photos.
• The photographs with no shooting direction indicated were taken from the top of the unit.
• Photos of AVR-X2300W E3 are used in this manual.
The viewpoint of each photograph
(Shooting direction : X) [View from the top]
Front side
Shooting
direction: D
Shooting
direction: C
↑Shooting direction: A↑
↓Shooting direction: B↓
Proceeding ： TOP COVER → COVER
(1) Remove the HOLDER. Remove the TAPE.
Proceeding ： TOP COVER → COVER → FRONT PANEL ASSY
(1) Remove the screws.
(2) Remove the screws. Remove the CORD HOLDER and connectors. Remove the FFC.
1. COVER
HOLDER
TAPE
2. FRONT PANEL ASSY
View from the bottom
x6
FFC FFC
N1008
CP4400
CORD HOLDER
63
Caution in
servicing
