Denon AVR-X2300W Service Manual

None of the pins are deformed.
There are deformed pins.
Check item (0) : Checking the HDMI connector
Checking the condition of the HDMI pin (rear/front).
Check for deformed pins.
OK NG
3. Check by following the ow chart for starting detection of the points
of failure.
Replace the HDMI connector.
HDMI "Rx/Tx" Failure Detection
1. Prior checking
81
Caution in
servicing
Electrical Mechanical Repair Information Updating
