Denon AVR-X2600H User Manual

Manual Setup
Perform when setting the speakers manually or when changing settings
made in Audyssey
®
Setup.
0
If you add or remove a speaker after performing Audyssey
®
Setup, you
will no longer be able to select Audyssey MultEQ
®
XT, Audyssey
Dynamic EQ
®
or Audyssey Dynamic Volume
®
. (v p. 156)
0
“Manual Setup” can be used without changing the settings. Please set if
necessary.
Amp Assign
Select the power amplifier usage method to match your speaker system.
See “Speaker configuration and “Amp Assign” settings” (v p. 40)
regarding the speaker configuration and connection.
o
Assign Mode
Select how to use the power amp.
Surround Back:
Setting for 7.1-channel playback using
surround back speakers.
Front Height:
Setting for 7.1-channel playback using
front height speakers.
Top Front:
Setting for 7.1-channel playback using
top front speakers.
Top Middle:
Setting for 7.1-channel playback using
top middle speakers.
Front Dolby:
Setting for 7.1-channel playback using
front Dolby Atmos Enabled speakers.
Surround Dolby:
Setting for 7.1-channel playback using
surround Dolby Atmos Enabled
speakers.
Contents Connections Playback Settings Tips Appendix
187
Front panel Display Rear panel Remote Index

Denon AVR-X2600H Specifications

General

Display	LCD
HDCP version	2.3
Product color	Black
Audio decoders	-
Volume control	Rotary
Audio amplifier	Yes
Amplifier output power	7 W
Audio formats supported	AAC, ALAC, FLAC, MP3, WAV, WMA
Supported radio bands	AM, FM
HDMI in	1
Certification	ISF
Power consumption (typical)	500 W
Receiver type	Surround
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W

Weight and Dimensions

Depth	237 mm
Width	434 mm
Height	341 mm
Weight	9500 g
