Denon AVR-X2800H User Manual

Inserting the batteries
1
Remove the rear lid in the direction of the arrow and
remove it.
2
Insert two batteries correctly into the battery
compartment as indicated.
Batteries
3
Put the rear cover back on.
NOTE
0
To prevent damage or leakage of battery fluid:
0
Do not use a new battery together with an old one.
0
Do not use two different types of batteries.
0
Remove the batteries from the remote control unit if it will not be in use for long
periods.
0
If the battery fluid should leak, carefully wipe the fluid off the inside of the battery
compartment and insert new batteries.
Operating range of the remote control
unit
Point the remote control unit at the remote sensor when operating it.
30° 30°
Approx. 7 m
Contents
Connections Playback Settings Tips Appendix
10
Front panel Display Rear panel Remote Index

Denon AVR-X2800H Specifications

General

Receiver type	stereo
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (20-20KHz@8 Ohm)	95 W
Display	LED
Apple docking	No
Product color	Black
Audio decoders	DTS Virtual:X, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	500 W
Operating temperature (T-T)	5 - 35 °C
Bluetooth version	4.2
Bluetooth profiles	A2DP, AVRCP, SBC
FM band range	87.5 - 108 MHz
Supported radio bands	DAB, FM, MW
Internet radio services supported	-
HDMI in	6
Digital audio coaxial in	1
Digital audio optical in	2
Speakers connectivity type	Clamp terminals

Weight and Dimensions

Depth	341 mm
Width	434 mm
Height	237 mm
Weight	9500 g
