Denon AVR-X2800H User Manual

Adjusting the tone (Tone)
Adjusts the tonal quality of the sound.
1
Press OPTION.
An option menu screen is displayed.
0
When the input source is “HEOS Music”, an option menu for
online music is displayed. Select “AVR Options…”, then press
ENTER.
2
Use cursor Up/Down to select “Tone”, then press
ENTER.
The “Tone” screen is displayed.
3
Use cursor Left/Right to set the tone control function to
on/off.
On: Allow tone adjustment (bass, treble).
Off
(Default):
Playback without tone adjustment.
4
Select “On” in step 3 and press cursor Down to select
the sound range to be adjusted.
Bass: Adjust bass.
Treble: Adjust treble.
5
Use cursor Left/Right to adjust the tone, then press
ENTER.
-6 dB – +6 dB (Default : 0 dB)
0
“Tone” settings are stored for each input source.
0
This cannot be set when the sound mode is set to “Direct” or “Pure Direct”.
0
This item cannot be set when “Dynamic EQ” is set to “On”. (v p. 178)
0
You cannot set this when no audio signal is input or in the menu “HDMI Audio Out”
is set to “TV”. (v p. 181)
Contents Connections Playback Settings Tips Appendix
130
Front panel Display Rear panel Remote Index

Denon AVR-X2800H Specifications

General

Receiver type	stereo
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (20-20KHz@8 Ohm)	95 W
Display	LED
Apple docking	No
Product color	Black
Audio decoders	DTS Virtual:X, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	500 W
Operating temperature (T-T)	5 - 35 °C
Bluetooth version	4.2
Bluetooth profiles	A2DP, AVRCP, SBC
FM band range	87.5 - 108 MHz
Supported radio bands	DAB, FM, MW
Internet radio services supported	-
HDMI in	6
Digital audio coaxial in	1
Digital audio optical in	2
Speakers connectivity type	Clamp terminals

Weight and Dimensions

Depth	341 mm
Width	434 mm
Height	237 mm
Weight	9500 g
