Denon AVR-X2800H User Manual

Calling up the settings
1
Press MAIN or ZONE2 to select the operating zone with
the remote control.
The button for the selected zone is lit.
2
Press QUICK SELECT.
The Quick Select settings registered to the button you pressed are
called up.
0
The default settings for the input source are as shown below.
GMAIN ZONEH
Button Input source
QUICK SELECT 1 CBL/SAT
QUICK SELECT 2 Blu-ray
QUICK SELECT 3 Media Player
QUICK SELECT 4 HEOS Music
GZONE2H
Button Input source
QUICK SELECT 1 CBL/SAT
QUICK SELECT 2 –
QUICK SELECT 3 –
QUICK SELECT 4 HEOS Music
0
Volume is not registered to Quick Select Plus in the factory default settings.
See “Changing the settings” to register volume to Quick Select Plus. (v p. 152)
Contents Connections Playback Settings Tips Appendix
151
Front panel Display Rear panel Remote Index

Denon AVR-X2800H Specifications

General

Receiver type	stereo
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (20-20KHz@8 Ohm)	95 W
Display	LED
Apple docking	No
Product color	Black
Audio decoders	DTS Virtual:X, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	500 W
Operating temperature (T-T)	5 - 35 °C
Bluetooth version	4.2
Bluetooth profiles	A2DP, AVRCP, SBC
FM band range	87.5 - 108 MHz
Supported radio bands	DAB, FM, MW
Internet radio services supported	-
HDMI in	6
Digital audio coaxial in	1
Digital audio optical in	2
Speakers connectivity type	Clamp terminals

Weight and Dimensions

Depth	341 mm
Width	434 mm
Height	237 mm
Weight	9500 g
