When performing Audyssey
®
Setup for the first time, the measurement data
is automatically saved to “Speaker Preset 1” of “Speaker Preset”.
0
If Audyssey
®
Setup has already been performed, the following “Speaker
Preset” selection screen is displayed.
Audyssey Setup
Back
Select which Preset to use. Preset 1 is already used,
selecting Preset 1 now will overwrite the previously stored
setting.
Speaker Preset 2
Speaker Preset 1
0
See “Speaker Preset” for detailed information on the Speaker Preset
function. (v p. 215)
13
Select “Details” and press ENTER to verify the
measurement results.
0
Subwoofers may measure a greater reported distance than the
actual distance due to added electrical delay common in
subwoofers.
NOTE
0
Do not enable new speakers in speaker configuration menu after Audyssey
®
Setup. If it is changed, run Audyssey
®
Setup again in order to configure the
optimum equalizer settings.
Contents
Connections Playback Settings Tips Appendix
202
Front panel Display Rear panel Remote Index

Denon AVR-X2800H Specifications

General

Receiver type	stereo
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (20-20KHz@8 Ohm)	95 W
Display	LED
Apple docking	No
Product color	Black
Audio decoders	DTS Virtual:X, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	500 W
Operating temperature (T-T)	5 - 35 °C
Bluetooth version	4.2
Bluetooth profiles	A2DP, AVRCP, SBC
FM band range	87.5 - 108 MHz
Supported radio bands	DAB, FM, MW
Internet radio services supported	-
HDMI in	6
Digital audio coaxial in	1
Digital audio optical in	2
Speakers connectivity type	Clamp terminals

Weight and Dimensions

Depth	341 mm
Width	434 mm
Height	237 mm
Weight	9500 g
