Denon AVR-X2800H User Manual

Listening to DAB broadcasts
1
Connect the antenna. (“Connecting a DAB/FM antenna
(for FM/DAB model only)” (v p. 62))
2
Press TUNER to switch the input source to “Tuner”.
3
Press OPTION.
The option menu screen is displayed.
4
Use cursor Up/Down to select “FM/DAB”, then press
ENTER.
This displays the reception band input screen.
5
Use cursor Left/Right to select “DAB”, then press
ENTER.
FM: When listening to an FM broadcast.
DAB: When listening to a DAB broadcast.
0
Automatically scans for DAB stations when DAB is selected for
the first time after purchase.
G TV screen H
OPTION
STEREO
CH 1
DAB Station -1
Genre
Tuner
Tune Preset
Option
Now Playing
01 DAB Station1
GDisplay of this unitH
6
Press TUNE + or TUNE – to select the station you want
listen to.
Operation buttons Function
TUNE +, – Selects the radio station (up/down)
CH/PAGE d f
Selects preset radio stations
Cursor Up/Down Selects the radio station (up/down)
Cursor Left/Right Selects preset radio stations
Contents Connections Playback Settings Tips Appendix
98
Front panel Display Rear panel Remote Index

Denon AVR-X2800H Specifications

General

Receiver type	stereo
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (20-20KHz@8 Ohm)	95 W
Display	LED
Apple docking	No
Product color	Black
Audio decoders	DTS Virtual:X, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	500 W
Operating temperature (T-T)	5 - 35 °C
Bluetooth version	4.2
Bluetooth profiles	A2DP, AVRCP, SBC
FM band range	87.5 - 108 MHz
Supported radio bands	DAB, FM, MW
Internet radio services supported	-
HDMI in	6
Digital audio coaxial in	1
Digital audio optical in	2
Speakers connectivity type	Clamp terminals

Weight and Dimensions

Depth	341 mm
Width	434 mm
Height	237 mm
Weight	9500 g
