Denon AVR-X3400H Service Manual

CAUTION IN SERVICING
SAFETY PRECAUTIONS
NOTE FOR SCHEMATIC DIAGRAM
NOTE FOR PARTS LIST
INSTRUCTIONS FOR HANDLING SEMICONDUCTORS AND OPTICAL UNIT
Online Parts List
Accessing the Parts List
Logging in to New SDI and Accessing the Parts List
Accessing the Part List from the Model Asset Screen
PRINTED CIRCUIT BOARDS Parts Table
Downloading the Parts List as an Excel File
Revision History
Searching Part Numbers or Ref. Numbers
CAUTION IN SERVICING.
Initializing This Unit
JIG FOR SERVICING
2
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X3400H Specifications

General

Receiver type	Surround
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby TrueHD
Audio formats supported	AAC, ALAC, FLAC, MP3, WAV, WMA
Supported radio bands	FM
Internet radio services supported	Deezer, Spotify, Tidal, TuneIn
HDMI in	8
Remote (IR) input	1
Composite video in	3
Component video (YPbPr/YCbCr) in	2
Multichannel audio output type	Terminals
Supported video modes	480i, 576i, 2160p
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Certification	ISF
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	10800 g
