Denon AVR-X3600H User Manual

Displaying your desired video during
audio playback (Video Select)
This unit can display video from a different source on TV during audio
playback. You can set this for each input source.
n
Supported input sources:
CD
z
/ Tuner / HEOS Music / Phono
z
This cannot be set when any of the HDMI, component video or video
connectors are assigned.
1
Press OPTION.
An option menu screen is displayed.
0
When the input source is “HEOS Music”, an option menu for
online music is displayed. Select “AVR Options…”, then press
ENTER.
2
Use ui to select “Video Select”, then press ENTER.
The “Video Select” screen is displayed.
3
Use o p to select the Video Select mode.
Off
(Default):
Disable Video Select mode.
On: Enable Video Select mode.
4
If you selected “On” in step 3, press i and select
“Source”.
5
Use o p to select the input source for video you want
to play back, then press ENTER.
0
“Video Select” settings are stored for each input source.
Contents Connections Playback Settings Tips Appendix
124
Front panel Display Rear panel Remote Index

Denon AVR-X3600H Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Pre-out channels	11.2
Pre-out connectivity	Yes
Audio output channels	9.2 channels
Dynamic power per channel (6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
Display	-
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Atmos, Dolby Surround, Dolby TrueHD
Audio formats supported	AAC, ALAC, FLAC, MP3, WAV, WMA
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Pandora, Spotify, Tidal, TuneIn
HDMI in	8
Composite video in	3
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Supported video modes	480i, 576i
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Package weight	14600 g
Cables included	AC
Speakers connectivity type	Binding post

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12100 g
