Denon AVR-X3600H User Manual

6
When the following screen is displayed, select “Begin
Test” and then press ENTER.
Start the measurement of the first position.
.
Begin Test
Back
Select “Begin Test” to start the calibration.
NOTE: You will hear a series of loud chirps starting and stopping
during the tests.
Audyssey Setup
Ear Height
0
Measurement requires several minutes.
NOTE
0
If “Caution!” is displayed on TV screen:
0
Go to “Error messages” (v p. 205). Check any related items, and
perform the necessary procedures.
0
If the volume level for the subwoofer is not appropriate, an error message
is displayed. See “Subwoofer level error message and how to adjust”
(v p. 206).
7
When the detected speaker is displayed, select “Next”
and then press ENTER.
.
Audyssey Setup
Repeat Last Test Next
Speaker Detection
Front
Center
Subwoofer
Surround
Surr. Back
:Yes
:Yes
:1spkr
:Yes
:No
Contents Connections Playback Settings Tips Appendix
201
Front panel Display Rear panel Remote Index

Denon AVR-X3600H Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Pre-out channels	11.2
Pre-out connectivity	Yes
Audio output channels	9.2 channels
Dynamic power per channel (6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
Display	-
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Atmos, Dolby Surround, Dolby TrueHD
Audio formats supported	AAC, ALAC, FLAC, MP3, WAV, WMA
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Pandora, Spotify, Tidal, TuneIn
HDMI in	8
Composite video in	3
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Supported video modes	480i, 576i
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Package weight	14600 g
Cables included	AC
Speakers connectivity type	Binding post

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12100 g
