Denon AVR-X3600H User Manual

Connecting to a home network (LAN)
This unit can connect to a network using a wired LAN or wireless LAN.
You can connect this unit to your home network (LAN) to enable various
types of playback and operations as described below.
0
Playback of network audio such as Internet Radio and from your media
server(s)
0
Playback of streaming music services
0
Using the Apple AirPlay function
0
Operation on this unit via the network
0
Operation with the HEOS wireless multi-room sound system
0
Firmware Update
For connections to the Internet, contact an ISP (Internet Service
Provider) or a computer shop.
Wired LAN
To make connections via wired LAN, use a LAN cable to connect the
router to this unit as shown in the figure below.
.
Internet
Modem
PC
Router
To WAN side
To LAN port
To LAN port
LAN port /
Ethernet
connector
LAN port /
Ethernet
connector
NAS
(Network Attached Storage)
Contents
Connections Playback Settings Tips Appendix
76
Front panel Display Rear panel Remote Index

Denon AVR-X3600H Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Pre-out channels	11.2
Pre-out connectivity	Yes
Audio output channels	9.2 channels
Dynamic power per channel (6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
Display	-
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Atmos, Dolby Surround, Dolby TrueHD
Audio formats supported	AAC, ALAC, FLAC, MP3, WAV, WMA
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Pandora, Spotify, Tidal, TuneIn
HDMI in	8
Composite video in	3
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Supported video modes	480i, 576i
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Package weight	14600 g
Cables included	AC
Speakers connectivity type	Binding post

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12100 g
