Denon AVR-X3700H User Manual

o
Pre-out
When “Assign Mode” is set to “11.1ch”, selects the PRE OUT
connector the external power amplifier used in MAIN ZONE.
The PRE OUT connectors that can be selected differ depending on the
combination of “Floor” and “Height” - “Layout” settings configured in
the menu.
This can be set when “5ch & SB” is set for “Floor” in the menu and four
Height and Dolby speakers in total are used.
HEIGHT 2z
(Default):
The Height2 left and right pre-amplifier
outputs are connected to an external
amplifier.
Front:
The Front left and right pre-amplifier
outputs are connected to an external
amplifier.
z
The name of the speaker is displayed that is set for the HEIGHT 2 speaker
terminals by the “Height” - “Layout” setting in the menu.
o
View Terminal Config.
This shows how to connect the speaker terminals and PRE OUT
connectors for your “Amp Assign” setting on the menu screen.
Contents Connections Playback Settings Tips Appendix
221
Front panel Display Rear panel Remote Index

Denon AVR-X3700H Specifications

General

Channels	9.2
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Built-in	Yes
Impedance	4 - 16 ohms
Frequency Response	10 Hz - 100 kHz
Input Sensitivity	200 mV
HDCP Support	2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Audio Return Channel (ARC)	eARC
Phono Input	Yes
Ethernet	Yes
USB	Yes
AM/FM Tuner	Yes
Power Output per Channel	105W (8 ohms, 20 Hz - 20 kHz, THD 0.08%, 2ch driven)
Signal-to-Noise Ratio	100 dB
Video Upscaling	Yes, up to 8K
Dimensions (W x H x D)	434 x 167 x 389 mm
Weight	12.5 kg
