Denon AVR-X3700H User Manual

o
Dimensions (Unit : in. (mm))
.
17.1 (434)
0.7
(18)
13.3 (339)
1.3
(32)
15.3 (389)
2.2
(57)
9.4 (237)
14.3 (363)
1.9
(47)
0.9
(22)
5.8 (148) 6.6 (167)
9.3 (236)
0.8
(19)
1.9 (47)13.3 (340)1.9 (47)
2.4
(60)
o
Weight: 27.6 lb (12.5 kg)
Contents Connections Playback Settings Tips Appendix
309
Front panel Display Rear panel Remote Index

Denon AVR-X3700H Specifications

General

Channels	9.2
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Built-in	Yes
Impedance	4 - 16 ohms
Frequency Response	10 Hz - 100 kHz
Input Sensitivity	200 mV
HDCP Support	2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Audio Return Channel (ARC)	eARC
Phono Input	Yes
Ethernet	Yes
USB	Yes
AM/FM Tuner	Yes
Power Output per Channel	105W (8 ohms, 20 Hz - 20 kHz, THD 0.08%, 2ch driven)
Signal-to-Noise Ratio	100 dB
Video Upscaling	Yes, up to 8K
Dimensions (W x H x D)	434 x 167 x 389 mm
Weight	12.5 kg
