Denon AVR-X3700H User Manual

o
About the cable labels (supplied) for channel identification
The channel display section for speaker terminals on the rear panel is color-coded for each channel to be identifiable.
Attach the cable label corresponding to each speaker to each speaker cable.
This makes it easy to connect the correct cable to the speaker terminals on the rear panel.
Speaker Color
FRONT L White
FRONT R Red
CENTER Green
SURROUND L Light Blue
SURROUND R Blue
SURROUND BACK L Beige
SURROUND BACK R Brown
FRONT HEIGHT L Light Yellow
FRONT HEIGHT R Yellow
TOP FRONT L Light Yellow
TOP FRONT R Yellow
TOP MIDDLE L Light Purple
TOP MIDDLE R Purple
Speaker Color
TOP REAR L Light Purple
TOP REAR R Purple
REAR HEIGHT L Light Purple
REAR HEIGHT R Purple
FRONT DOLBY L Light Yellow
FRONT DOLBY R Yellow
SURROUND DOLBY L Light Purple
SURROUND DOLBY R Purple
BACK DOLBY L Light Purple
BACK DOLBY R Purple
SUBWOOFER 1 Black
SUBWOOFER 2 Black
Contents Connections Playback Settings Tips Appendix
39
Front panel Display Rear panel Remote Index

Denon AVR-X3700H Specifications

General

Channels	9.2
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Built-in	Yes
Impedance	4 - 16 ohms
Frequency Response	10 Hz - 100 kHz
Input Sensitivity	200 mV
HDCP Support	2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Audio Return Channel (ARC)	eARC
Phono Input	Yes
Ethernet	Yes
USB	Yes
AM/FM Tuner	Yes
Power Output per Channel	105W (8 ohms, 20 Hz - 20 kHz, THD 0.08%, 2ch driven)
Signal-to-Noise Ratio	100 dB
Video Upscaling	Yes, up to 8K
Dimensions (W x H x D)	434 x 167 x 389 mm
Weight	12.5 kg
