Connecting 7.1-channel speakers
o
Example connections when using surround back speakers
This 7.1-channel surround system is the same as a basic 5.1-channel system but with surround back speakers.
.
0
Set “Floor” to “5ch & SB” in the menu when connecting in this configuration.
(v p. 217)
.
FRONT FRONT
CENTER
SURROUND SURROUND
SURROUND BACK SURROUND BACK
ASSIGNABLE ASSIGNABLE
SPEAKERS
FR FL C SR SL
SW
SBR SBL
0
When using a single surround back speaker, connect it to the SURROUND BACK
L terminal.
