Denon AVR-X3700H User Manual

Connecting 7.1-channel speakers: Second pair of front speakers
This system enables switching playback between front speakers A and B as desired.
You can connect speakers for up to 9-channels for MAIN ZONE. When you connect speakers for 8 or more channels, the output speakers automatically
switch according to the input signal and sound mode.
.
FHL
SW
C
SL
SBL
FHR
SR
SBR
FLFL
(B) (A)
FRFR
(A) (B)
.
ASSIGNABLE ASSIGNABLE
FRONT FRONT
CENTER
SURROUND SURROUND
HEIGHT1 HEIGHT1 HEIGHT2 HEIGHT2
SURROUND BACK SURROUND BACK
SPEAKERS
SBR SBL
CSRSL
SW
FR
(A)
FL
(A)
FHR FHL
zz
FR
(B)
FL
(B)
z
The height speakers, ceiling speakers and Dolby Atmos Enabled speakers can
be connected to the HEIGHT1 speaker terminals. Set the speaker to be
connected from “Height” - “Layout” in the menu. (v p. 219)
Contents
Connections Playback Settings Tips Appendix
60
Front panel Display Rear panel Remote Index

Denon AVR-X3700H Specifications

General

Channels	9.2
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Built-in	Yes
Impedance	4 - 16 ohms
Frequency Response	10 Hz - 100 kHz
Input Sensitivity	200 mV
HDCP Support	2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Audio Return Channel (ARC)	eARC
Phono Input	Yes
Ethernet	Yes
USB	Yes
AM/FM Tuner	Yes
Power Output per Channel	105W (8 ohms, 20 Hz - 20 kHz, THD 0.08%, 2ch driven)
Signal-to-Noise Ratio	100 dB
Video Upscaling	Yes, up to 8K
Dimensions (W x H x D)	434 x 167 x 389 mm
Weight	12.5 kg
