Connecting an external power amplifier
You can use this unit as a pre-amp by connecting an external power amplifier to the PRE OUT connectors. By adding a power amplifier to each channel,
the realness of the sound can be further enhanced.
Select the terminal to use and connect the device.
0
Set “Assign Mode” to “Pre Amplifier” if connecting all
channels to the Pre-out connectors using an external
amplifier. (v p. 217)
This stops operation of the internal power amplifier of this
unit, reducing interference in the pre amplifier created by
the power amplifier.
0
When using just one surround back speaker, connect it to
the left channel (L) terminal.
L
L
R
R
L
L
R
R
L
L
R
R
L
L
R
R
L
L
R
R
CENTER
RL
FRONT
AUDIO
SUB-
WOOFER
2
AUDIO
SUB-
WOOFER
1
AUDIO
SURROUND
BACK
RL
SURROUND
RL
RL
HEIGHT2 HEIGHT1
RL
Subwoofer
(Primary)
Subwoofer
(Secondary)
Power amplifier
Contents
Connections Playback Settings Tips Appendix
63
Front panel Display Rear panel Remote Index

Denon AVR-X3700H Specifications

General

Channels	9.2
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Built-in	Yes
Impedance	4 - 16 ohms
Frequency Response	10 Hz - 100 kHz
Input Sensitivity	200 mV
HDCP Support	2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Audio Return Channel (ARC)	eARC
Phono Input	Yes
Ethernet	Yes
USB	Yes
AM/FM Tuner	Yes
Power Output per Channel	105W (8 ohms, 20 Hz - 20 kHz, THD 0.08%, 2ch driven)
Signal-to-Noise Ratio	100 dB
Video Upscaling	Yes, up to 8K
Dimensions (W x H x D)	434 x 167 x 389 mm
Weight	12.5 kg
