Denon AVR-X3700H User Manual

Connecting to a home network (LAN)
This unit can connect to a network using a wired LAN or wireless LAN.
You can connect this unit to your home network (LAN) to enable various
types of playback and operations as described below.
0
Playback of network audio such as Internet Radio and from your media
server(s)
0
Playback of streaming music services
0
Using the Apple AirPlay function
0
Operation on this unit via the network
0
Operation with the HEOS wireless multi-room sound system
0
Firmware Update
For connections to the Internet, contact an ISP (Internet Service
Provider) or a computer shop.
Wired LAN
To make connections via wired LAN, use a LAN cable to connect the
router to this unit as shown in the figure below.
.
Internet
Modem
PC
Router
To WAN side
To LAN port
To LAN port
LAN port /
Ethernet
connector
LAN port /
Ethernet
connector
NAS
(Network Attached Storage)
Contents
Connections Playback Settings Tips Appendix
77
Front panel Display Rear panel Remote Index

Denon AVR-X3700H Specifications

General

Channels	9.2
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Built-in	Yes
Impedance	4 - 16 ohms
Frequency Response	10 Hz - 100 kHz
Input Sensitivity	200 mV
HDCP Support	2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Audio Return Channel (ARC)	eARC
Phono Input	Yes
Ethernet	Yes
USB	Yes
AM/FM Tuner	Yes
Power Output per Channel	105W (8 ohms, 20 Hz - 20 kHz, THD 0.08%, 2ch driven)
Signal-to-Noise Ratio	100 dB
Video Upscaling	Yes, up to 8K
Dimensions (W x H x D)	434 x 167 x 389 mm
Weight	12.5 kg
