Sound mode that can be selected for each input signal
0
The following sound modes can be selected using the MOVIE, MUSIC and GAME buttons.
0
Adjust the sound field effect with the menu “Surround Parameter” to enjoy surround sound the way you like it. (v p. 163)
Stereo
SSS
Dolby Surround SSS
DTS Neural:X SSS
DTS Virtual:X z2z4z5
z2z3
z2z3
SSS
Auro-3D z2z6 SSS
Auro-2D Surround z2 z3 SSS
Multi Ch Stereo SS
S
Mono Movie
S
Rock Arena
S
Jazz Club
S
Matrix
S
Video Game
GAME buttonMUSIC buttonMOVIE buttonSound modeInput signal
2-channel z1
z1
2-channel also includes analog input.
z2
It cannot be selected when headhones are used.
z3
It cannot be selected when the speaker configuration is front speakers only.
z4
It cannot be selected when a speaker configuration with any height speakers is used.
z5
It cannot be selected when the input signal is Dolby Digital, Dolby Digital Plus, Dolby TrueHD or Dolby Atmos.
z6
It cannot be selected when a speaker configuration without front height or front Dolby Atmos Enabled speakers is used.
Contents Connections Playback Settings Tips Appendix
134
Front panel Display Rear panel Remote Index

Denon AVR-X3800H Specifications

General

Channels	9.4
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
Voice Control	Yes (Amazon Alexa, Google Assistant, Apple Siri)
eARC	Yes
Input Sensitivity/Impedance	200 mV / 47 kohms
Ethernet	Yes
Phono Input	Yes
AM/FM Tuner	Yes
Audyssey Room Correction	Audyssey MultEQ XT32
HDR Compatibility	HDR10+, Dolby Vision, HLG
Streaming	Spotify, Tidal
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
USB Port	Yes
Signal-to-Noise Ratio	100 dB (IHF-A weighted, Direct mode)
