Denon AVR-X3800H User Manual

n
Front Layout / Middle Layout / Rear Layout
Set the speaker layout when installing 2 sets (4-channels) or more of Height, Ceiling or Dolby Atmos Enabled speakers.
The layouts that can be selected differ depending on the combinations of “Assign Mode” and “Floor” in the menu. (“Assign Mode” (v p. 204),
“Floor” (v p. 206))
[4-channel heigh speakes]
Settings AUDIO OUT connectors
Height Sp Dolby Sp NOTE Front Layout Rear Layout HEIGHT 1 HEIGHT 2
4ch None
Front Height Top Middle Front Height Top Middle
Front Height Top Rear Front Height Top Rear
Front Height Rear Height Front Height Rear Height
Front Height Surround Height Front Height Surround Height
Top Front Top Rear Top Front Top Rear
Top Front Rear Height Top Front Rear Height
Top Middle Rear Height Top Middle Rear Height
2ch 2ch
Front Height Surround Dolby Front Height Surround Dolby
Front Height
Back Dolbyz1
Front Height Back Dolby
Top Front Surround Dolby Top Front Surround Dolby
Top Front
Back Dolbyz1
Top Front Back Dolby
Front Dolby Top Rear Front Dolby Top Rear
Front Dolby Rear Height Front Dolby Rear Height
None 4ch
Front Dolby Surround Dolby Front Dolby Surround Dolby
Front Dolby
Back Dolbyz1
Front Dolby Back Dolby
Contents Connections Playback Settings Tips Appendix
209
Front panel Display Rear panel Remote Index

Denon AVR-X3800H Specifications

General

Channels	9.4
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
Voice Control	Yes (Amazon Alexa, Google Assistant, Apple Siri)
eARC	Yes
Input Sensitivity/Impedance	200 mV / 47 kohms
Ethernet	Yes
Phono Input	Yes
AM/FM Tuner	Yes
Audyssey Room Correction	Audyssey MultEQ XT32
HDR Compatibility	HDR10+, Dolby Vision, HLG
Streaming	Spotify, Tidal
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
USB Port	Yes
Signal-to-Noise Ratio	100 dB (IHF-A weighted, Direct mode)
