Denon AVR-X3800H User Manual

0
This unit is compatible with Dolby Atmos and DTS:X which offers an even wider
and deeper surround sensation.
0
The “Speaker Virtualizer” must be set to “On” for Dolby Atmos playback with 5.1-
channel speaker configurations or less. (v p. 165)
0
IMAX DTS:X / DTS:X can be selected regardless of the speaker configuration.
0
Auro-3D recommends adding FRONT HEIGHT and SURROUND HEIGHT
speakers to a 5.1 speaker configuration. Optionally, you may substitute REAR
HEIGHT, Dolby Atmos Enabled speakers instead of FRONT HEIGHT and
SURROUND HEIGHT speakers for Dolby Atmos, DTS:X and Auro-3D playback.
o
Recommended placement of the speakers
Floor speakers Layout
0
Use the following illustration as a guide for the installation location of
each floor speaker. You do not have to match them exactly.
FL
SW
C
SL
FR
SR
SBL
SBR
z2
z1
z3
z
1 22° - 30°
z
2 90° - 110°
z
3 135° - 150°
0
If you are not using the surround back speakers, the recommended angle of the
surround sound speakers (
z
2) is 120°.
0
When using a single surround back speaker, place it directly behind the listening
position.
Contents
Connections Playback Settings Tips Appendix
36
Front panel Display Rear panel Remote Index

Denon AVR-X3800H Specifications

General

Channels	9.4
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
Voice Control	Yes (Amazon Alexa, Google Assistant, Apple Siri)
eARC	Yes
Input Sensitivity/Impedance	200 mV / 47 kohms
Ethernet	Yes
Phono Input	Yes
AM/FM Tuner	Yes
Audyssey Room Correction	Audyssey MultEQ XT32
HDR Compatibility	HDR10+, Dolby Vision, HLG
Streaming	Spotify, Tidal
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
USB Port	Yes
Signal-to-Noise Ratio	100 dB (IHF-A weighted, Direct mode)
