About the cable labels (supplied) for channel identification
The channel display section for speaker terminals on the rear panel is color-coded for each channel to be identifiable.
Attach the cable label corresponding to each speaker to each speaker cable.
This makes it easy to connect the correct cable to the speaker terminals on the rear panel.
Speaker Color
FRONT L White
FRONT R Red
CENTER Green
SURROUND L Light Blue
SURROUND R Blue
SURROUND BACK L Beige
SURROUND BACK R Brown
FRONT HEIGHT L Light Yellow
FRONT HEIGHT R Yellow
TOP FRONT L Light Yellow
TOP FRONT R Yellow
TOP MIDDLE L Light Purple
TOP MIDDLE R Purple
TOP REAR L Light Purple
TOP REAR R Purple
Speaker Color
SURROUND HEIGHT L Light Purple
SURROUND HEIGHT R Purple
REAR HEIGHT L Light Purple
REAR HEIGHT R Purple
TOP SURROUND Beige
CENTER HEIGHT Brown
FRONT DOLBY L Light Yellow
FRONT DOLBY R Yellow
SURROUND DOLBY L Light Purple
SURROUND DOLBY R Purple
BACK DOLBY L Light Purple
BACK DOLBY R Purple
SUBWOOFER 1 Black
SUBWOOFER 2 Black
SUBWOOFER 3 Black
SUBWOOFER 4 Black
Contents Connections Playback Settings Tips Appendix
40
Front panel Display Rear panel Remote Index

Denon AVR-X3800H Specifications

General

Channels	9.4
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
Voice Control	Yes (Amazon Alexa, Google Assistant, Apple Siri)
eARC	Yes
Input Sensitivity/Impedance	200 mV / 47 kohms
Ethernet	Yes
Phono Input	Yes
AM/FM Tuner	Yes
Audyssey Room Correction	Audyssey MultEQ XT32
HDR Compatibility	HDR10+, Dolby Vision, HLG
Streaming	Spotify, Tidal
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
USB Port	Yes
Signal-to-Noise Ratio	100 dB (IHF-A weighted, Direct mode)
