Denon AVR-X3800H User Manual

Connecting speakers to the speaker terminals
You can connect 11.4 channel speakers to this unit.
The speaker terminals can perform simultaneous playback for up to 9 channels. Use in combination with pre-out terminals if you wish to perform
simultaneous playback for 11 channels. Refer to “Amp Assign” for details. (v p. 204)
Connect each speaker according to the speakers you are using.
z
1
When using a single surround back speaker, connect it to the
SURROUND BACK L terminal.
z2
The output terminals for Height/Ceiling/Dolby Atmos Enabled speakers
vary according to the speaker combination that you use. For the
speaker terminal that connects each Height/Ceiling/Dolby Atmos
Enabled speaker, refer to “Amp Assign” - “Layout” (v p. 208).
SW1 SW2 SW3 SW4
SR SLFR FL C RHR RHLFHR FHL
SBLSBR
z
1
z
2
z
2
z
2
z
2
Contents
Connections Playback Settings Tips Appendix
42
Front panel Display Rear panel Remote Index

Denon AVR-X3800H Specifications

General

Channels	9.4
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
Voice Control	Yes (Amazon Alexa, Google Assistant, Apple Siri)
eARC	Yes
Input Sensitivity/Impedance	200 mV / 47 kohms
Ethernet	Yes
Phono Input	Yes
AM/FM Tuner	Yes
Audyssey Room Correction	Audyssey MultEQ XT32
HDR Compatibility	HDR10+, Dolby Vision, HLG
Streaming	Spotify, Tidal
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
USB Port	Yes
Signal-to-Noise Ratio	100 dB (IHF-A weighted, Direct mode)
