Page #209 background imageLoading...
Page #209 background image
Source Level
This function corrects the playback level of the selected input source’s
audio input.
Make this setting if there are differences in the input volume levels
between the different sources.
o
Source Level
n
When the input source is set to “HEOS Music” or
“Tuner”
-12 dB – +12 dB (Default : 0 dB)
o
Analog Inputs / Digital Inputs
n
When the input source is set other than to “HEOS
Music” or “Tuner”
-12dB – +12dB (Default : 0dB)
0
The analog input level can be adjusted independently for input sources for which
“ANALOG” is assigned at “Input Assign”. (v
p. 206)
0
The digital input level can be adjusted independently for input sources for which
“DIGITAL” is assigned at “Input Assign”. (v p. 206)
0
“Source Level” settings are stored for each input source.
Input Select
Set the audio input mode of each input source.
The input modes available for selection may vary depending on the input
source.
0
“Input Select” settings are stored for each input source.
o
Input Mode
Set the audio input modes for the different input sources.
It is normally recommended to set the audio input mode to “Auto”.
Auto
(Default):
Automatically detect input signal and
perform playback.
HDMI: Play only signals from HDMI input.
Digital: Play only signals from digital audio input.
Analog: Play only signals from analog audio input.
0
When digital signals are properly input, the ~ indicator lights on the display.
If the ~ indicator does not light, check “Input Assign” and the connections.
(v p. 206)
0
If “HDMI Control” is set to “On” and a TV compatible with the ARC is
connected via the HDMI MONITOR 1 connectors, the input mode whose input
source is “TV Audio” is fixed to ARC.
Contents Connections Playback Settings Tips Appendix
209
Front panel Display Rear panel Remote Index
