Denon AVR-X4500H User Manual

Accessories
8
Inserting the batteries
9
Operating range of the remote control unit
9
Features
10
High quality sound
10
High performance
13
Easy operation
17
Part names and functions
18
Front panel
18
Display
22
Rear panel
24
Remote control unit
28
Connections
Speaker installation
32
Connecting speakers
40
Before connecting speakers
40
Speaker configuration and “Amp Assign” settings
44
Connecting 5.1-channel speakers
46
Connecting 7.1-channel speakers
47
Connecting 9.1-channel speakers
51
Connecting 11.1-channel speakers
59
Connecting 7.1-channel speakers: Bi-amp connection of front
speakers
65
Connecting 7.1-channel speakers: Second pair of front speakers
66
Connecting multi-zone speakers
67
Connecting a TV
72
Connection 1 : TV equipped with an HDMI connector and
compatible with the ARC (Audio Return Channel)
73
Connection 2 : TV equipped with an HDMI connector and
incompatible with the ARC (Audio Return Channel)
74
Connection 3 : TV equipped without an HDMI connector
75
Connecting a playback device
76
Connecting a set-top box (Satellite tuner/cable TV)
77
Connecting a DVD player or Blu-ray Disc player
78
Connecting a Blu-ray Disc player compatible with the Denon Link
HD function
79
Connecting a video camcorder or game console
80
Connecting a turntable
81
Connecting a USB memory device to the USB port
82
Connecting an FM/AM antenna
83
Connecting to a home network (LAN)
85
Wired LAN
85
Wireless LAN
86
Connecting an external control device
87
REMOTE CONTROL jacks
87
TRIGGER OUT jacks
88
Connecting the power cord
89
Contents Connections Playback Settings Tips Appendix
2
Front panel Display Rear panel Remote Index

Denon AVR-X4500H Specifications

General

Display	-
Quantity	1
HDCP version	2.2
Apple docking	No
Product color	Silver
Audio decoders	DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume control	Rotary
Audio amplifier	Yes
Multi-Zone quantity	3
Connector contacts plating	Gold
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (20-20KHz@8 Ohm)	125 W
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, TuneIn, iHeartRadio
HDMI in	8
Audio (L/R) in	5
Composite video in	4
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	13500 g
