Music files on PC or NAS cannot be played back
Files stored on a computer cannot be played.
0
Files are stored in a non-compatible format. Record in a compatible format. (v
p. 303)
0
Files that are copyright protected cannot be played on this unit.
0
The USB port of this unit cannot be used for connection to a computer.
0
Media sharing settings on the server or NAS do not allow this unit. Change the settings to allow this unit. For details, see the owner’s manual of the
server or NAS.
Server is not found, or it is not possible to connect to the server.
0
The computer’s or router’s firewall is activated. Check the computer’s or router’s firewall settings.
0
Computer’s power is not turned on. Turn on the power.
0
Server is not running. Launch the server.
0
IP address of this unit is wrong. Check the IP address of this unit. (v p. 241)
Music files on PC cannot be played back.
0
Even if PC is connected to the USB port on this unit, music files on it cannot be played back. Connect PC to this unit through the network. (v p. 85)
Files on PC or NAS are not displayed.
0
Files of a type not supported by this unit are not displayed. (v p. 303)
Music stored on a NAS cannot be played.
0
If you use a NAS in conformity with the DLNA standard, enable the DLNA server function in the NAS setting.
0
If you use a NAS that does not conform with the DLNA standard, play the music via a PC. Set Windows Media Player’s media sharing function and add
NAS to the selected play folder.
0
If connection is restricted, set audio equipment as the connection target.
Contents
Connections Playback Settings Tips Appendix
289
Front panel Display Rear panel Remote Index

Other manuals for Denon AVR-X4500H

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X4500H and is the answer not in the manual?

Denon AVR-X4500H Specifications

General IconGeneral
Display-
Quantity1
HDCP version2.2
Apple dockingNo
Product colorSilver
Audio decodersDTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume controlRotary
Audio amplifierYes
Multi-Zone quantity3
Connector contacts platingGold
Receiver typeSurround
Frequency range10 - 100000 Hz
Audio output channels9.2 channels
Signal-to-Noise Ratio (SNR)100 dB
Power output per channel (20-20KHz@8 Ohm)125 W
FM band range87.5 - 108 MHz
Supported radio bandsAM, FM
Internet radio services supportedAmazon Music, Deezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, TuneIn, iHeartRadio
HDMI in8
Audio (L/R) in5
Composite video in4
Component video (YPbPr/YCbCr) in2
Connectivity technologyWired
AC input voltage230 V
AC input frequency50 Hz
Power consumption (standby)0.1 W
Power consumption (typical)710 W
Weight and Dimensions IconWeight and Dimensions
Depth389 mm
Width434 mm
Height167 mm
Weight13500 g
