The combination of the HEIGHT1 and HEIGHT2 channels can be changed to the following patterns according to the speaker system being used.
Set this from “Amp Assign” in the menu. (v
p. 221)
Combination of height speakers to be used Connected terminals
Number of height/
ceiling speakers
Number of Dolby
Speakers
Combination pattern HEIGHT1 SPEAKER HEIGHT2 PRE OUT
2 speakers None
Front Height Front Height -
Top Front Top Front -
Top Middle Top Middle -
Top Rear Top Rear -
Rear Height Rear Height -
4 speakers None
Front Height & Top Middle Front Height Top Middle
Front Height & Top Rear Front Height Top Rear
Front Height & Rear Height z
Front Height Rear Height
Front Height & Surr. Height Front Height Surr. Height
Top Front & Top Rear Top Front Top Rear
Top Front & Rear Height Top Front Rear Height
Top Middle & Rear Height Top Middle Rear Height
None 2 speakers
Front Dolby Front Dolby -
Surround Dolby Surround Dolby -
Back Dolby Back Dolby -
2 speakers 2 speakers
Front Dolby & Top Rear Front Dolby Top Rear
Front Dolby & Rear Height Front Dolby Rear Height
Front Height & Surr. Dolby Front Height Surround Dolby
Front Height & Back Dolby Front Height Back Dolby
Top Front & Surround Dolby Top Front Surround Dolby
Top Front & Back Dolby Top Front Back Dolby
None 4 speakers
Front Dolby & Surround Dolby Front Dolby Surround Dolby
Front Dolby & Back Dolby Front Dolby Back Dolby
