Denon AVR-X4800H User Manual

Setting items Detailed items Description Page
.
General
Language Changes the language of the display on the TV screen. 253
ECO Configures the ECO Mode and Auto Standby energy-saving functions. 253
ZONE2 Setup/
ZONE3 Setup
Makes settings for audio playback with ZONE2 and ZONE3. 257
Zone Rename Changes the display title of each zone to one you prefer. 259
Quick Select Names Changes the Quick Select Name display title to one you prefer. 259
Trigger Out 1/
Trigger Out 2
Select the conditions for activating trigger out function. 260
Front Display Makes settings related to the display on this unit. 260
Firmware Checks for the latest firmware information about updates and upgrades, updates the
firmware, and sets up the notification message display.
261
Information Shows information about this unit settings, input signals, etc. 264
Usage Data Selects whether or not to send anonymous usage data to Denon. 265
Save & Load Save and restore device settings by using a USB memory device. 266
Setup Lock Protects settings from inadvertent changes. 266
Reset Various settings are reset to the factory default values. 267
.
Setup Assistant
Begin Setup... Performs basic installation/connections/settings from the beginning according to the
guidance indicated on the TV screen.
Page 9 of
the separate
manual
“Quick Start
Guide”
Language Select Sets individual setting items according to the guidance displayed on the TV screen.
Speaker Setup
Speaker Calibration
Network Setup
TV Audio Connection
Input Setup
Mobile Apps
Contents Connections Playback Settings Tips Appendix
178
Front panel Display Rear panel Remote Index

Denon AVR-X4800H Specifications

General

Channels	9.4
Dolby Atmos	Yes
DTS:X	Yes
HDMI Inputs	7
HDMI Outputs	3
4K/120Hz Pass-through	Yes
8K Support	Yes
Wi-Fi	Yes (2.4GHz/5GHz)
Bluetooth	Yes
HEOS Built-in	Yes
Amplifier Channels	9
Power Output per Channel @ 8 Ohms / 1 kHz / 0.08% THD / 2 Channels Driven	125W
Speaker Impedance	4-16 Ohms
Auro 3D	Yes
IMAX Enhanced	Yes
HDCP Support	2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
eARC Support	Yes
Phono Input	Yes
Ethernet	Yes
Voice Assistant Support	Amazon Alexa, Google Assistant, Apple Siri
Audyssey MultEQ XT32	Yes
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Network Connectivity	Ethernet, Wi-Fi
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Dimensions (W x H x D)	434 x 167 x 389 mm
Weight	13.5 kg
Power Output per Channel	125W
Voice Control	Yes
Frequency Response	10 Hz - 100 kHz
DAC	32-bit AKM
Video Pass-Through	8K
Zone Audio Output	Zone 2, Zone 3
Wireless Audio Streaming	Yes
Signal-to-Noise Ratio	102 dB
Video Inputs/Outputs	7/3 (HDMI)
Audio Inputs/Outputs	7 HDMI inputs, 3 HDMI outputs, 1 phono input, 2 optical inputs, 1 coaxial input
