Denon AVR-X4800H User Manual

3
Connect the Sound calibration microphone to the
SETUP MIC jack of this unit.
.
When the Sound calibration microphone is
connected, the following screen is displayed.
.
Audyssey Setup
Dolby Speaker Setup
Channel Select
Amp Assign
Start
Your AV receiver can automatically measure the acoustics of
your room then optimize your speakers using the included
microphone and microphone stand.
Set the following items
if necessary.
4
Select “Start”, then press ENTER.
Audyssey
®
Setup can also make the following settings.
0
Amp Assign
The signals output from the HEIGHT1 and HEIGHT2 speaker
terminals can be switched in accordance with your speaker
environment. (“ Amp Assign ” (v p. 225))
0
Channel Select
If channels that are not to be used are set in advance,
measurement for the set channels is skipped, and measuring
time can be reduced. You can also change the number of
surround back speakers and subwoofer.
0
Dolby Speaker Setup
Set the distance between the Dolby Atmos Enabled speaker and
the ceiling.
This can be set when using the Front Dolby Atmos Enabled,
Surround Dolby Atmos Enabled or Back Dolby Atmos Enabled
speaker.
5
Follow the instructions on the screen display and press
“Next” to proceed further.
Contents Connections Playback Settings Tips Appendix
217
Front panel Display Rear panel Remote Index

Denon AVR-X4800H Specifications

General

Channels	9.4
Dolby Atmos	Yes
DTS:X	Yes
HDMI Inputs	7
HDMI Outputs	3
4K/120Hz Pass-through	Yes
8K Support	Yes
Wi-Fi	Yes (2.4GHz/5GHz)
Bluetooth	Yes
HEOS Built-in	Yes
Amplifier Channels	9
Power Output per Channel @ 8 Ohms / 1 kHz / 0.08% THD / 2 Channels Driven	125W
Speaker Impedance	4-16 Ohms
Auro 3D	Yes
IMAX Enhanced	Yes
HDCP Support	2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
eARC Support	Yes
Phono Input	Yes
Ethernet	Yes
Voice Assistant Support	Amazon Alexa, Google Assistant, Apple Siri
Audyssey MultEQ XT32	Yes
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Network Connectivity	Ethernet, Wi-Fi
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Dimensions (W x H x D)	434 x 167 x 389 mm
Weight	13.5 kg
Power Output per Channel	125W
Voice Control	Yes
Frequency Response	10 Hz - 100 kHz
DAC	32-bit AKM
Video Pass-Through	8K
Zone Audio Output	Zone 2, Zone 3
Wireless Audio Streaming	Yes
Signal-to-Noise Ratio	102 dB
Video Inputs/Outputs	7/3 (HDMI)
Audio Inputs/Outputs	7 HDMI inputs, 3 HDMI outputs, 1 phono input, 2 optical inputs, 1 coaxial input
