Cannot connect to a wireless LAN network
Cannot connect to the network.
0
The network name (SSID), password and encryption setting have not been set up correctly. Configure the network settings according to the setting
details of this unit. (v p. 247)
0
Shorten the distance from the wireless LAN access point and remove any obstructions to improve access first before re-connecting again. Place the
unit away from microwave ovens and other network access points.
0
Configure the access point channel settings away from channels that are being used by other networks.
0
This unit is not compatible with WEP (TSN).
Cannot connect to a WPS Router.
0
Check that the WPS mode of the router is operating.
0
Press the WPS button on the router and then press the “Connect” button displayed on the TV within 2 minutes.
0
A router/settings that are compatible with WPS 2.0 standards are required. Set the encryption time to “None”, “WPA-PSK (AES)” or WPA2-PSK (AES).
(v
p. 247)
0
If the router encryption method is WEP/WPA-TKIP/WPA2-TKIP, you cannot connect by using the WPS button on the router. In this case, use the “Scan
Networks” or “Manual” method to connect.
Cannot connect to the network using iPhone/iPod touch/iPad.
0
Update the iPhone/iPod touch/iPad firmware to the latest version.
0
When configuring the settings via a wireless connection, iOS 7 or later needs to be supported.
Contents
Connections Playback Settings Tips Appendix
296
Front panel Display Rear panel Remote Index

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X4800H and is the answer not in the manual?

Denon AVR-X4800H Specifications

General IconGeneral
Channels9.4
Dolby AtmosYes
DTS:XYes
HDMI Inputs7
HDMI Outputs3
4K/120Hz Pass-throughYes
8K SupportYes
Wi-FiYes (2.4GHz/5GHz)
BluetoothYes
HEOS Built-inYes
Amplifier Channels9
Power Output per Channel @ 8 Ohms / 1 kHz / 0.08% THD / 2 Channels Driven125W
Speaker Impedance4-16 Ohms
Auro 3DYes
IMAX EnhancedYes
HDCP Support2.3
HDR CompatibilityHDR10, HDR10+, Dolby Vision, HLG
eARC SupportYes
Phono InputYes
EthernetYes
Voice Assistant SupportAmazon Alexa, Google Assistant, Apple Siri
Audyssey MultEQ XT32Yes
Total Harmonic Distortion0.05%
Input Sensitivity/Impedance200 mV / 47 kOhms
Network ConnectivityEthernet, Wi-Fi
Supported Audio FormatsMP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Dimensions (W x H x D)434 x 167 x 389 mm
Weight13.5 kg
Power Output per Channel125W
Voice ControlYes
Frequency Response10 Hz - 100 kHz
DAC32-bit AKM
Video Pass-Through8K
Zone Audio OutputZone 2, Zone 3
Wireless Audio StreamingYes
Signal-to-Noise Ratio102 dB
Video Inputs/Outputs7/3 (HDMI)
Audio Inputs/Outputs7 HDMI inputs, 3 HDMI outputs, 1 phono input, 2 optical inputs, 1 coaxial input
