27
Ref. No. Part No. Part Name Remarks Q’ty
OTHER PARTS GROUP
CX21 203 2349 009 2P inlet 1
CX22 205 0581 001 2P VH connector base 1
CX41 205 0343 045 4P connector base (KR-PH) 1
CX51,52 205 0343 058 5P connector base (KR-PH) 2
CX53 205 0190 052 5P NH connector base 1
CX61 205 0343 061 6P connector base (KR-PH) 1
CX63 205 0190 065 6P NH connector base 1
CX141 204 6504 005 14P PH-SAN connector cord 1
CX161 205 0892 033 16P FFC base (P=1) 1
CX271 205 0880 016 27P FFC connector base 1
CY22 205 0581 001 2P VH connector base 1
CY41 205 0343 045 4P connector base (KR-PH) 1
CY52 205 0355 059 5P KR connector base (L) 1
CY141 205 0375 042 14P connector base (KR-PH) 1
CY271 205 0880 016 27P FFC connector base 1
FB101 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT 1
FB102 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT 2
DCD-685 model only
FB103,104 235 0129 901 Chip emifil2
FB105 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT 1
DCD-685 model only
FB107,108 235 0129 901 Chip emifil2
FB109 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT 1
FB110 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT 2
DCD-685 model only
FB112-115 235 0129 901 Chip emifil4
FB116 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT 1
DCD-685 model only
FB118 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT 1
DCD-685 model only
FB119,120 235 0129 901 Chip emifil2
FB121 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT 1
DCD-685 model only
FB123 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT 1
DCD-685 model only
FB125 235 0129 901 Chip emifil1
FB126,127 235 0049 900 Beads inductor 2
FL601 393 8021 006 VFD 1
JK101 269 0188 000 TOTX178 1
JK301 204 8537 009 2P pin jack (GNB) D 1
JK401 204 8264 071 Headphone jack (gold) 1
L501 239 8019 002 Line filter coil DCD-485 model only1
S501 212 1030 009 Power switch (TV-5) 1
S601-610 212 5604 910 Tact switch 10
S611 212 0410 002 Rotary encoder-jog 1
S614 212 5604 910 Tact switch 1
S617 212 5604 910 Tact switch 1
S618-620 212 5604 910 Tact switch DCD-685 model only4
S619 212 5604 910 Tact switch DCD-485 model only1
Ref. No. Part No. Part Name Remarks Q’ty
ST1,2 205 0452 017 Style pin 2
ST501,502 205 0452 017 Style pin 2
TM501 412 9483 009 Earth plate 1
W701 203 0539 031 1P SIN cord Ass'y 1
X101 399 0743 005 Crystal 8.4672 MHz DCD-685 model only1
X103 399 0742 006 Crystal 16.9344 MHz DCD-485 model only1
X601 399 0755 909 Ceramic resonator4.23MHz CSTS0423MG06-T2 1
461 0862 045 FL spacer (T=5) under FL601 2
412 4809 002 IC Heat spreader 1
417 0579 001 HEAT SINK assembled with TR502 1
