70DCD-SA100

PARTS LIST OF EXPLODED VIEW

＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。

Ref.No. PartNo. PartName Remarks Q'ty New

1 1U-3532 CD/SACDP.W.BUNIT 1

1-1 FRONTAUDIOUNIT

1-2 SURROUNDAUDIOUNIT

1-3 JUNCTIONUNIT

2 1U-3533 POWER/DISPLAYUNIT 1

2-1 POWERUNIT

2-2 DISPLAYUNIT

2-3 LEDUNIT

2-4 P.SWUNIT

3 1U-3562 SACDMODULEUNIT 1

4 1290263009 TRANSSHEET(B) 1

5 1051436004 REARPANEL 1 *

! 6 2033962003 ACINLET 1

7 1051152100 INSIDEBOTTOM 1

8 1051151305 BOTTOMCOVER 1

9 1290212005 FOOTDAMPER 4

10 1040296006 FOOTASS'Y 4

11 4125042004 MECHABRACKETBOTTOM 1 *

12 4112030100 TRANSPLATE 1

13 1290260002 TRANSSHEET 1

! 14 2330665003 POWERTRANS(A/D) 1 *

15 4150809005 WASHER 3

★ 16 4458004007 WIRECLAMPER 3

17 4122814073 CARDSPACER(L=18) 5

18 4125015002 P.W.B.BRACKET 2

19 4125013004 P.W.B.SIDEBRACKET 1

20 FGSA100 SACDMECHAUNIT 1

21 4111318205 FRONTANGLE 1

22 1442838208 FRONTPANELASS'Y 1 *

23 1461542627 FLHOLDER 1 *

24 1431173000 DISPLAYSHEET 1 *

25 1131705037 INPUTKNOB 1

26 1131705040 OP/CLKNOB 1

27 1131706227 FUNCTIONKNOB 1

28 GEN6387 BLINDSUBASS'Y 1

29 4630958007 SPRING 2 *

30 4450048003 CORDHOLDER(L76) 1

31 1131942007 POWERKNOBASS'Y 1

32 1442839100 LOADERPANELASS'Y 1 *

33 1020593017 TOPCOVER 1

34 4411709103 TOPCOVERDAMPER 1

35 4150930000 DAMP.SHEET 1 *

36 4125041005 MECHABRACKETTOP 1 *

37 4112037006 CHASSIS 1 *

★ 38 5131581008 SERIALNO.SHEET 1

39 4149095008 CUDAMPER 1

50 - BUTYLTAPE(W50T2) 長さ：70、MECHABRACKETTOP に貼る 4

51 - NITOFLONTAPE(W50T0.08) 長さ：70、B.TAPE に貼る 4

52 - BUTYLTAPE(W25T2) 長さ：50、F.P. と F.A. にまたいで貼る 2

53 - NITOFLONTAPE(W25T0.08) 長さ：50、B.TAPE に貼る 2

54 - BUTYLTAPE(W50T2) 長さ：130、P.TRANS 上に貼る 1

55 - NITOFLONTAPE(W50T0.08) 長さ：130、B.TAPE に貼る 1

56 - BUTYLTAPE(W50T2) 長さ：80、P.TRANS 下に貼る 2
