73DCD-SA100
PARTS LIST OF SACD MECHANISM
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
Ref. No. Part No. Part Name Remarks Q'ty New
1 411 1988 101 MECHA CHASSIS 1
2 431 0426 503 PLATE GEAR 1
3 9KA 2A40 3D GEAR BASE SUB ASS'Y 1
4 441 1952 109 GEAR BASE ASS'Y 1
5 9KM 01T1 32 LD MOTOR 1
6-1 9KA 85P0 05 DETECTOR SW P.W.B. 1
6-2 9KA 85G0 27 2P CONNECTOR WIRE 1
6-3 9KA 82G3 08 2P CONNECTOR 1
6-4 9KS 01W1 48 DETECTOR SW 1
7 421 0772 108 MOTOR PULLY 1
8 424 0269 209 GEAR C 1
9 424 0268 200 GEAR B 2
10 424 0267 201 GEAR A 1
11 424 0270 104 PULLEY GEAR 1
12 423 0077 100 BELT 1
13 446 0063 007 MECHA FRAME 1
14 9KA 2A50 6A TRAV. MECHA 1 *
15 9KC 2G08 3A DAMPER-IDLE 4
16 424 0246 109 LOADER GEAR 1
17 431 0427 405 LOADER 1
18 461 1131 005 RUBBER FORM 1
19 461 1131 018 RUBBER FORM 1
20 412 4817 104 LOADER BRACKET 1
21 431 0384 001 SLIDE SHAFT 1
22 431 0428 006 HOLDER 1
23 412 4818 006 BEARING PLATE ASS'Y 1
24 1U- 3562 SACD MODULE P.W.B. UNIT 1 *
25 009 0186 015 24P FFC CABLE (0.5) 1
26 412 5041 005 MECHA BRACKET TOP 1 *
27 412 4820 201 CLAMP BASE 1
28 9KA 7G20 3B CLAMPER L 1
29 9KA 7P08 5A CLAMPER T 1
30 9KA 7G20 2D CLAMPER H 1
31 403 0061 002 CLAMP BASE DAMPER 1
SCREWS
50 471 9057 007 SPECIAL SCREW M1.7 2
51 9KM 01T1 32 SCREW 2.6X2.5 CBS-NI 2
52 471 3813 001 SCREW 2.6X4 CBS-B 4
53 9KH 26P0 08 SCREW 2.6X8 CFTS(P) 5
54 473 7511 004 SCREW 3X10 CFTS (P)-Z 1
55 473 7508 017 SCREW 3X10 CBTS (P)-B 16
56 473 7508 046 SCREW 3X16 CBTS (P)-B 2
57 477 0262 006 SPECIAL SCREW 2
58 9KC 1H01 1A SCW-DAMPER 4
59 9KP 36C6 25 SLIT WASHER 1
60 9KP 26C6 25 SLIT WASHER 1
61 473 7002 021 SCREW 3X8 CBTS (S)-B 4
